Comparison Page

Wall Attached Screen Rooms

Do-It-Yourself Screen Enclosures and Patio Room Kits



Delivery Included!
All pricing includes delivery to your home, business or cottage address in or
near most major centres within Canada.
√ Delivery Included!* | √ No Handling Fees | √ Only applicable taxes are extra

*Some exceptions may apply.
*Click for details

Got Questions? Call 1.800.922.4760Do you have questions?
We would love to help! Call and talk it through with us.

Call: 1-800-922-4760...

We provide personal service and advice on your selection. Please call or email us with your questions on deck size, clearances, installation advice and tips. We are here to serve.






Wall Attached Screened Enclosures

Patio Sunroom

Screened Patio Room


Upper End Quality
Screened Walls

Upper End Quality

Best Vinyl Top

Mylar Windows

Mid-Range Price

Heavy Duty Welded Vinyl Top

Optional Mylar Windows

Key Differences

Custom Sizes - Permanent Screened Enclosure

All Weather, Permanent 3-Season Sunroom,

Thick Vinyl Top (22 oz.) Elegant and Sturdy. Very impressive quality and appearance

Spring & Summer use, High Quality (14 oz.) Heat Sealed Vinyl Top. All parts Are aluminum with stainless steel bolts. No Rusting.

Excellent Value

Key Advantage

Permanent Installation

Permanent Sunroom at a lower price

Exceptional Quality,

Most features of any room, Moderately Priced

DIY Setup Difficulty Level

Set up in hours


1-2 day setup

Moderately Easy

5-7 Hours

Delivery Status

3-4 Weeks

4-5 Weeks

3-4 Weeks

(Distance away from house wall)
Dependant on your existing roofline - no limitations

10, 11, 12,

13 or 14

7 6, 10 or 11 3

Widths available Dependant on your existing roofline - no limitations

10, 11, 12, 13, 14,

 15, 16, 17 or 18

10, 11 3, 15,

18 9 22 6, 26 3,

30, 33 9 or 37

Back Wall Heights Dependant on your existing roofline - no limitations

Minimum 94 7/8 (varies depending on projection)

- Minimum 91 to a maximum 107

- Roof gables are custom designed to be level at all heights


One Year

Five Years

One Year

Color choices Frame: White, Bronze or Beige

Frame: White or Beige
Top: 5 Color Choices

Frame: Taupe or White
Top: 6 Color choices

General Construction 2"x2" & 1"x2" Extruded Aluminum framing

All 'U' channels extruded aluminum

Fiberglass screens, Kick plate is an available option

1/8 Thick Extruded Aluminum Load Bearing Framing.

Fiberglass screens, Kick plate, Sliding Polymer interior windows included. Patented roof tensioning system. Excellent Roof Overhang and water drainage

44 wide x 74 high Aluminum Screen Frames, joined with Vinyl Hinge, Fiberglass Screens.
Interior wind & privacy panels available. Easy roof tensioning system, built into a 5" roof overhang so that the rain water does not wash down the front screens.





Wall Attached Screened Enclosures

Patio Sunroom

Screened Patio Room

Door Single out swinging screen door with kick-plate

- Single Swing-in door, heavy duty Mylar windows & side lites.


- Optional doors in almost any position

- Single Aluminum Sliding door may be positioned to suit your deck.


- Additional Sliding doors available. All sliding doors on rollers for easy use.


Your existing roof line!


- Heaviest Vinyl top available. Full 22 oz for maximum strength against wind, rain and snow.


- Double valence for sharp appearance.


- Roof overhang of 5 to allow rain water to drain away from windows help to keep interior dry and for better appearance.


  Load supporting 2 x 1 rafters with 3 x 5 lateral support beam.

- Heavy duty 14 oz vinyl top, Heat sealed means no sewn seams for longer lasting leak proof use.


- Top has front and side tightening system using threaded extension bolts and tie down sides, front overhang 4 5


- Rafters are 1 round galvalume tubing. Top wraps around tubing for appearance and to prevent flapping in higher winds.

Standard Walls consist of:

Horizontal extrusions are 1" x 2"

Vertical extrusions are 2" x 2"

You can place the support bar, which is on the inside of the screen panels, anywhere within the range of center height to 1/3 height.

This means that you can create a clear line of sight for when you are seated in the room.

Your choice of no kick-plates or 18" or 24" kick-plates

- Full Heavy Duty Sliding Mylar Windows with screens included.


- Side walls are 78 high, 56 Wide.


- Walls completely assembled in kit form.


- Wall Frames are extruded Aluminum in Beige or White


- Aluminum Framed Full Screen wall, floor to ceiling.


- Divided by frame support 2/3 top, 1/3 bottom, for unobstructed view when seated.


- Screen frames are standard 74 high plus 2 roof support beam


- Standard Fiberglass screening, easily replaced if damaged


- Frame and door widths are 44 plus joining vinyl hinge





Wall Attached Screened Enclosures

Patio Sunroom

Screened Patio Room


- Extra Doors


- Extra Doors


- Extra doors (Positioned anywhere you need them)

- 74 Frame Height

- Custom Back Wall height

- Inserts to enclose all or part of room. All with Aluminum frame, Mylar or Vinyl insert with quick release frame lock. Light and easy to handle. Upper 2/3 inserts are hinged for flexibility of use.

- Mylar: See through, clear or tinted.

- Vinyl: Full privacy, White for maximum brightness or a color to match the top.

Maintenance No maintenance

Clean roof and windows yearly.

Recommended removal of top for winter months.

(15 - 20 minutes)



We carry over 100 different combinations of gazebos in sizes and colors designed to fit most decks and patios.
If you don't see it here, call us, we will be pleased to advise and assist.


**COMPARE!**  Easy reference comparison

Check out our Free Standing Screen Enclosure Comparison Page!

Print Stand Alone Screen Room Comparison Page


**COMPARE!**  Easy reference comparison
Check out our Wall Attached Screen Enclosure Comparison Page!

Print Wall Attached
Comparison Page


Call: 1-800-922-4760 and talk with our experts. We provide personal service and advice on your selection. Please call or email us with your questions and installation advice and tips. We are here to serve. *Delivery Included within Canada. (*Some remote and island ferry access areas subject to a surcharge)

Obtaining necessary permits is the sole responsibility of the purchaser. Customers agree to hold Patio Concepts Inc. and the manufacturer free of any liability for improper installation, maintenance and repair.

**Please note that most items are custom made and are not returnable**
Current delivery is in the 3-4 week range.
