W Pan Carport System

W Pan Aluminum Patio Covers

Aluminum Pan System Patio Awnings and Carports

Do It Yourself! You've been putting it off! Now is the time to put up that new W pan patio cover. Protect your car from the elements or your backyard deck
from the sun.


Our aluminum W Pan systems are made for all municipal load ratings and are the ultimate in strong, durable aluminum, low maintenance, do it yourself kits


Made in Canada with high quality materials, our W pan patio covers come with full instructions and are designed according to IBC standards meeting all municipal load ratings.

do it yourself kits...
window awning, door canopy, fabric and aluminum awnings


Prices are in
Canadian  Dollars
for delivery to Canadian addresses

Delivery Included!

All pricing includes delivery to your home, business or cottage address in or near most major centres within Canada:

√ Delivery Included!*

√ No Handling Fees

√ Only applicable taxes are extra

*Some exceptions may apply. *Click for details


Patio Cover Solutions

Fixed Aluminum & Retractable


         Insulated Roof Patio Covers

        Aluminum W Pan Patio Covers

                  W Pan Picture Gallery

                  How to Get A Quotation

                  Let's Talk Snow Loads

                  Installation Instructions

        Aluminum Flat Pan Patio Covers
        Retractable Fabric Patio Covers

        Fixed Vinyl Patio Covers


Our "Solutions" Department

Freestanding and 3 sided


Screen Walls Only System


Manual & Motorized


A line from Arrow Shed Ind.


A huge selection from SunSetter


Auto & RV Covers from ShelterLogic


Agricultural Applications


Fixed and Retractable


Fabric and Aluminum


No maintenance PVC


Do it yourself window awning kits, deck enclosure kits, garage shelter kits, and backyard storage shed kits are all worthwhile home improvements. You'll enjoy them now, and you'll appreciate the value they add to your home should you
ever go to sell.

Do you have questions?
We have answers! Give us a call and talk it through with us.

Call: 1-800-922-4760...


We provide personal service and advice on your selection. Please call or email us with your questions on deck size, clearances, installation advice and tips. We are here to serve you!


Stop the sun from fading carpets, draperies and upholstery by installing a new window awning. We have both fabric  and aluminum window awnings in a fixed or roll up format.

Our manual or motorized vertical rollup shade blinds are a perfect late afternoon protection from the sun.

Backyard accents like garden arbours are an easy and inexpensive way to add elegance to any garden-scape.


My Patio Concepts Inc
                 1 . 8 0 0 . 9 2 2 . 4 7 6 0
Bookmark this page!


W Pan Patio Cover SystemTwo gauges of aluminum pans, beams and posts - all in several colors and an unlimited size range! Designed for "on site" final cuts by you, this unit adds value and functionality to any home while giving the homeowner the satisfaction and flexibility to do it themselves.

The aluminum pan system patio covers are ideal for the price conscious home owner, while still giving a practical professional looking finished product.


Check out our specials listed below!


     W Pan Profile12" wide x 3" high

Features & Specifications:


The Northlander W PAN Patio Cover Systems come with... Instructions, fascia gutter, aluminum side fascia, 12" wide 'W' pans, screws, sealant, downspout assembly, beam and posts as necessary.

  1. W Pan CutawayAll quoted units are designed to meet 2009 IBC standards using live load ratings of 20 - 80 pounds per square foot (psf) and wind ratings of 50-100 miles per hour (mph) respectively.

  2. Simple span load table given below for your convenience

  3. All front heights should be calculated on a specification of
    a 1" - 2" drop per foot of projection.

  4. Both Wall attached and Free-standing systems available

  5. Projection (pan direction) is indicated as the distance away from the house, from the house wall to the front of the unit.

  6. Width is the distance along the house wall that the unit is to span.

  7. Your posts will need to be spaced according to the IBC standard determined by the required load rating (see point #1).

  8. Tools You May here

  • Northlander Patio Cover is built to your specifications

  • Durable baked-on enamel finish never needs painting

  • Northlander Patio Cover has built-in large capacity gutter system

  • Strong, sturdy all aluminum construction resists Canadian weather.

  • Provide protection without complicated construction

  • (1) Downspout assembly is quoted unless otherwise requested

  • Flashing requirements must be purchased locally

  • Designed and engineered for loading in your area.

  • Also available in 'free standing configurations.

  • All aluminum components ensure a rust free, long life!

Insulated Patio Cover "Quick Links..."
Tools You May here
Pictures and Details Page
Click here for all you will need to get a quote from us...

Prices in ($) CAN for Delivery Included to most major centres

Call 1.800.922.4760 to place your order

 Apart from the specials listed below, almost any size you need is possible. We would be pleased to provide you with a quotation. In order to get a quote... You will FIRST need to call your local building department to get the required load ratings for your area. Click here to know what you need for a quotation...

2016 - - 20' Wide Specials!
Each of the 20' wide units below come with: Instructions, extruded aluminum front gutters, extruded aluminum side fascias, 12" wide .040" thick 'W' pans, 22' beam (where indicated - cut to finished size by customer on site) screws, sealant, single downspout assembly, (4) 8' x  3" x 3" x .090" posts, top and bottom brackets and covers. Your unit must be anchored properly to be in accordance with all live load ratings.

(projection x width)

Quote #

# of Posts

Beam -
(1) 22 ft.

Live Load Rating
@ 90mph winds

Beam Placement
(out from wall)

Maximum distance between posts
( 40 lbs./sq.ft. rating)

CAN $  -
Credit Card

Delivery Included

8' x 20'



3" x 3" x 22'

40 lbs./sq.ft.


7'8" $2909.35

10' x 20'



3" x 3" x 22'


6'8" $3325.40

12' x 20'



3" x 3" x 22'


6'1" $3808.90

14' x 20'



3" x 3" x 22'


5'7" $4221.60
    OR Get a 5% Discount by sending a Certified Cheque                  Call 1.800.922.4760


Not included:

  • You will need to supply the hardware to attach the hanger channel to the home/trailer

  • You will need to supply any flashing that you may desire to further waterproof your back-wall connection.

Maximum Panel Simple Span Load Table


.032" Pan Thickness .040" Pan Thickness Attention:

This table does not
replace the customer's requirement to research
their own municipal
load requirements!

6' 75 lbs./sq. ft. over 80 lbs./sq. ft.
7' 56 lbs./sq. ft. 75 lbs./sq. ft.
8' 42 lbs./sq. ft. 57 lbs./sq. ft.
9' 34 lbs./sq. ft. 45 lbs./sq. ft.
10' 27 lbs./sq. ft. 36 lbs./sq. ft.
11' 22 lbs./sq. ft. 30 lbs./sq. ft.
12' 19 lbs./sq. ft. 25 lbs./sq. ft.
13' n/a 22 lbs./sq. ft.
14' n/a 19 lbs./sq. ft.

Our units are pre-engineered systems that have been approved by qualified, provincially approved engineers. Our systems are rated according to 2009 International Building Codes. Snow drifting and wind uplift have not been considered in the wall attached units. If local specifications require such engineering, these standards can be met at an additional cost. Current approved standards assume an importance factor equal to 1 & wind exposure equal to "B". If you require documentation and registered engineering stamps we will submit your request with your quotation. We cannot talk to engineers about such items prior to knowing what it is you require.
